Electrical Pump
The pump is a plunger type, it needs to be driven by a motor and recommend using electric motor. These pumps can be used on wellhead control panel systems, Power packs on high-torque service tools. The pump application medium is hydraulic oil and it needs to be installed at a lower position than the tank. Before starting the pump, you must vent the air in the pump chamber.
Features
★ Choice of 4 ratios: 0.64 l/min, 1.02 l/min, 1.4 l/min, 2.1 l/min.
★ High-strength alloy steel pump body and stainless steel shell optional.
★ Low power consumption and very low noise.
★ Standard Buna N seals for -29~120°C service, other seals available.
★ Output pressure up to 15000 psi (1034 bar).
★ Pump can rotate clockwise and counterclockwise.
PRODUCT CODE | （RatedPress.） | （Max.IntermittentPress.） | flow rate @1500rpm | Max.Speed | 进口接口 | 出口接口 |
ELP-4A03N | 10000psi（690bar） | 15000psi（1034bar） | 0.64l/min | 3000rpm | 1/2"NPT | 1/4"NPT |
ELP-4A04N | 10000psi（690bar） | 15000psi（1034bar） | 1.02l/min | 3000rpm | 1/2"NPT | 1/4"NPT |
ELP-4A05N | 10000psi（690bar） | 15000psi（1034bar） | 1.4l/min | 3000rpm | 1/2"NPT | 1/4"NPT |
ELP-4A06N | 10000psi（690bar） | 15000psi（1034bar） | 2.1l/min | 3000rpm | 1/2"NPT | 1/4"NPT |
Manual Pump
Manual pump provide a low cost efficient means for manually increasing pressure in a hydraulic system where emergency standby power is needed. Before increasing pressure, please use the handlebar to close the vent valve if there is one.
Features
★ Can be repaired without removing the pump from system
★ Replaceable pump spool.
★ Piston hardened and ground.
★ 27" handle bar reduces the operating force.
PRODUCT CODE | material | code | Drain port | |
MP- | SS- | 0A- | V | |
MP | SS-316SS | 0A | 20000 psig, Single Piston, 2.6 mL | emptyy-NO |
SL-316L SS | 1A | 10000 psig, Single Piston, 4.1 mL | V-YES | |
S4-304SS | 2A | 5000 psig, Single Piston, 9.2 mL | ||
CS-carbonstell | 3A | 2500 psig, Single Piston, 17.7 mL | ||
For special requirement please contact the Sales Department. | ||||
